Main Power 15Kw Door Frame Cold Roll Forming Machine Automatic Type
PLC System Control
1. Product Description
| 1 | Name of commodity & specification | door frame cold roll forming machine
|
| 2 | Main motor power | 18.5kw, 3 phase |
| 3 | Hydraulic motor power | 15kw |
| 4 | Hydraulic Pressure | 18-20MPa |
| 5 | Voltage | 380V /3phase/ 50 HZ (or as your requirement) |
| 6 | Control System | PLC Delta Inverter |
| 7 | Main Frame | 350mm H-Beam |
| 8 | Backboard Thickness | 18mm |
| 9 | Chain Size | 66mm |
| 10 | Feeding Material | color steel coils |
| 11 | Feeding Thickness | 1.5-3.2mm |
| 12 | Feeding Width | mm |
| 13 | Effective width | 80-300mm |
| 14 | Productivity | 12-14m/min |
| 15 | Roll Station | 12 |
| 16 | Roller Diameter | 80mm |
| 17 | Roller material | 45# steel |
| 18 | Cutter material | Cr12 , quenched |
| 19 | Cr-Plating Size | 0.05mm |
| 20 | Overall Size | 9500×1400×1350mm |
| 21 | Total Weight | 6T |
| 22 | Components | Manual Uncoiler-------------------1 set
Guiding Platform------------------1 set
Coil Strip Leveler------------------1 set
Main Machine of Roll Forming------1 set
Electric-Motor---------------------1 set
Hole-Punch Device--------1 set
Cutting Device--------------------1 set
Hydraulic Station------------------1 set
PLC Control-----------------------1 set
Supporter Table-------------------1 set |
| 23 | Workflow | Manual decoiling----feeding and guiding----roll
forming----punching----cut to length----run out table |
| | |
| 24 | Package | nude in the container |
| 25 | Minimum order quantity | 1 set |
| 26 | Payment terms | T/T(30% T/T pay in advance, the remaining 70% pay before ship) |
| | |
| 27 | Delivery time | 30 working days later after receiving the deposit |
2. Production process
3. PLC Control System
1. Adopts PLC control technology, frequency adjust speed
technology, realize the automatic production.
2. Provide good man and machine screen, which can set the batches,
plate length, and quantity.
3. Operation type: Touching screen + Button
4. Using encoder to calculate the number and measuring the length
5. Electrical control: PLC frequency control system with touch
screen
4.Main Components
| Decoiler / Uncoiler | 1 Unit |
| Feeding Guide | 1 Unit |
| Main Roll Forming Machine | 1 Unit |
| Heating Device | 1 Unit |
| PU Injection Foaming Machine | 1 Unit |
| Pneumatic Tracking Punching | 1 Unit |
| Servo Flying-saw Cutting | 1 Unit |
| PLC Electrical Control Board | 1 Unit |
| Run out Support Table | 1 Unit |
